What’s the Difference?

When selecting a pump for water supply, irrigation, or industrial systems, two common options are jet pumps and centrifugal pumps. Both pumps move water using centrifugal force, but they are designed for different situations and operating conditions.

Understanding the differences between jet pumps and centrifugal pumps can help contractors, engineers, and property owners choose the most effective pump for their system.

What Is a Jet Pump?

A jet pump is commonly used to draw water from wells or underground sources. It works by using a Venturi nozzle system that creates suction, allowing the pump to pull water from deeper depths.

Jet pumps are typically installed above ground and use either a single pipe or a two-pipe system to pull water up from the well. Because of their design, jet pumps can lift water from deeper levels than many standard surface pumps.

Jet pumps are often used in:

• Private well water systems


• Residential water supply systems


• Rural properties without municipal water


• Shallow or deep well applications


There are two main types of jet pumps:

Shallow well jet pumps, which typically work at depths up to about 25 feet.

Deep well jet pumps, which can draw water from depths of 100 feet or more using a two-pipe system.

Jet pumps are valued for their ability to lift water from deeper sources, although they typically produce lower flow rates compared to other pump types.

What Is a Centrifugal Pump?

A centrifugal pump is one of the most widely used pump designs in commercial and industrial systems. It uses a rotating impeller to create centrifugal force, pushing water outward through the pump and into the piping system.

Unlike jet pumps, centrifugal pumps are typically used in applications where water is already available at the surface or where suction depth is limited.

Centrifugal pumps are commonly used in:

• Irrigation systems


• Water transfer between tanks


• Industrial water circulation


• HVAC systems


• Cooling water systems


Because centrifugal pumps move water efficiently, they are known for delivering high flow rates with relatively simple mechanical design.

Key Differences Between Jet Pumps and Centrifugal Pumps

The main difference between these two pumps is how they move water and the depth from which they can draw it.

Jet pumps are designed to pull water from deeper underground sources by creating suction using a Venturi nozzle system. Centrifugal pumps typically rely on gravity-fed or shallow suction sources and cannot lift water from very deep levels.

Another difference is performance characteristics. Jet pumps tend to generate higher pressure but lower flow rates, while centrifugal pumps are better suited for high-flow applications with moderate pressure requirements.

Noise levels and efficiency can also vary. Jet pumps are generally louder and less energy-efficient, while centrifugal pumps tend to operate more quietly and efficiently in many surface water applications.

When Should You Use a Jet Pump?

Jet pumps are typically used when water must be drawn from a well or underground water source.

They are commonly installed in systems where:

• Water must be lifted from deep wells


• A property relies on a private well for water supply


• The pump must be installed above ground


• Higher suction capability is required


In these cases, the jet pump’s ability to create strong suction makes it a practical solution.

When Should You Use a Centrifugal Pump?

Centrifugal pumps are ideal for systems where water is already available at the surface or where the pump does not need to pull water from deep underground sources.

Typical uses include:

• Irrigation and agricultural systems


• Industrial water circulation


• Moving water between tanks or reservoirs


• Cooling systems in commercial buildings


• Municipal water transfer applications


These pumps are often chosen because they are efficient, reliable, and capable of moving large volumes of water.

Choosing the Right Pump for Your System

Selecting between a jet pump and a centrifugal pump depends on several factors, including:

• Depth of the water source


• Required flow rate


• Pressure requirements


• Installation location


• System efficiency considerations


In systems where water must be lifted from deeper wells, jet pumps are often the better choice. For surface water transfer or high-flow systems, centrifugal pumps are typically the more efficient solution.

Final Thoughts

Jet pumps and centrifugal pumps both play important roles in water supply and pumping systems.

Jet pumps are designed to draw water from deeper underground sources using suction and pressure. Centrifugal pumps are designed to move large volumes of water efficiently in surface or shallow water systems.

Understanding how these pumps work and where they perform best helps ensure the right equipment is selected for reliable and efficient operation.
